From this page you can purchase exhaust gasket sheet from 1.0 to 3mm thickness.
Remember that as a general rule you should select the thinnest material possible
for your application.
General Properties of exhaust gasket sheet is made from two sides 0.2-0.25mm
tanged tinplate with asbestos beater sheet insert. It generally used in high
temperature and high pressure environments, and commonly finds applications in
steam exhaust applications.
If you can’t find what you’re looking for, of require a bespoke material, please
do not hesitate to contact us.
Is exhaust gasket sheet the Best Material for My Application? If you are unsure
as to which material is best for your application then you can consult our
gasket material selector, or our guide to rubbers. Material specifications can
be downloaded from the link on the left of this page.
Alternatively, we are always happy to offer technical help and advice and so if
you require assistance then please do not hesitate to contact us.
Product Specification
• Supplier = Cling-Seal
• Condition = New
• Thicknesses Available = 1.0mm- 3mm;3.0mm-6.0mm
• Sheet Size Available = 500*500mm,500*1000mm,1000*1000mm,1000*1500mm,Etc
|
Item |
Data |
|
Compressibility (%,at
34.5 MPa) |
8-17 |
|
Recovery(%) |
≥35 |
|
150℃，At ASTM 3#Oil for
5hours |
Weight Increase(%) |
≤30 |
|
Thickness Increase(%) |
≤20 |
|
At 21℃~30℃，ASTM B Fuel
for 5hours |
Weight Increase(%) |
≤30 |
|
Thickness Increase(%) |
≤20 |
Product Technical Details
As a general rule, exhaust gasket sheet is:
• Good for use with steam
• Good ozone resistance
• Good with high pressure
Customer Service
We are happy to answer any questions that you might have about this product.
Please contact us for more information.
|
